Description
| Model | MWX1500-12-1 | MWX1500-12-2 | MWX1500-24-1 | MWX1500-24-2 | MWX1500-48-1 | MWX1500-48-2 |
| Rated Power | 1500W | |||||
| Surge Power | 3000W | |||||
| Input Voltage | 12VDC | 24VDC | 48VDC | |||
| Output Voltage | 110VAC±5% | 220VAC±5% | 110VAC±5% | 220VAC±5% | 110VAC±5% | 220VAC±5% |
| USB Port | 5V 1000MA | |||||
| Frequency | 50HZ±3 or 60HZ±3 | |||||
| Output Waveform | Modified sine wave | |||||
| Soft Start | YES | |||||
| THD/AC Regulation | THD＜3%(Linear Load) | |||||
| Output Effciency | 94% MAX | |||||
| No Load Current | 1.2A | 1.2A | 0.6A | 0.6A | 0.3A | 0.3A |
| DC Voltage Range | 10V-15.5V | 10V-15.5V | 20V-31V | 20V-31V | 40V-60V | 40V-60V |
| Low Voltage Alarm | 10.5±0.5V | 21±0.5V | 42±1V | |||
| low Voltage Shut Down | 10±0.5V | 20±0.5V | 40±1V | |||
| Low Voltage Recovery | 13±0.5V | 24±0.5V | 48±1V | |||
| Over Voltage Shut Down | 15.5±0.5V | 31±0.5V | 60±1V | |||
| Over Voltage Recovery | 14.8±0.5V | 29±0.5V | 59±1V | |||
| Cooling Way | Intelligent Cooling Fan | |||||
| Protection | Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit | |||||
| Working Temperature | （-10℃+60℃ Civil class，-25℃+60℃ technical grade，-40℃+70℃ army grade） | |||||
| Storage Temperature | （-10℃ – 60℃） | |||||
| Humidity | 90% MAX，Non-condensing | |||||
| Warranty | 1 Years | |||||
| Net Dimension | 286*165*87 | |||||
| Package Dimension | 365*200*130 | |||||
| N.W./Unit/G.W./Unit | 2.8kg/3.5Kg | |||||
| Ctn | 8PCS | |||||
| Meas./Ctn | 520*475*380 | |||||
| G.W./Ctn | 23kg | |||||
